1. Main

The M300 series Cellular Modem is a complete wireless USB data modem providing global cellular network connectivity, where cellular signal available, with 4G/3G/2G fallback capabilities for ensured access to the internet anywhere.

The M300 is an easy to install productivity tool designed to provide maximum accessibility to the mobile professional allowing quick access to the internet for real-time business transactions, email, web browsing and more.

E-Lins' mobile data products are widely used in more than 50 countries and regions, and more than twenty industrial fields, such as power control, water schedule, traffic, oil field, weather forecast, environmental protection, street lamp control, post, bank and many other areas.

2. Hot Spot

Built-in 2G/3G/4G industrial cellular module, insert SIM/UIM card to work directly;

Built-in sim card slot;

Broadband M2M communications

SIM failover/standby APN

3G/4G failover for fixed line broadband connections

Rapid service deployment applications

Support At command

USB port

MIMO support (option)

GPS support (option)

3. Wireless M2M Application

Remote Data Monitor and Control

CCTV, security surveillance

Water, gas and oil flow metering and schedule

AMR (automatic meter reading)

Power station monitoring and control

Remote POS (point of sale) terminals, ATM,

Traffic signals monitor and control, Traffic info guidance

Oil field, weather forecast, environmental protection, street lamp monitoring and control

Early Warning of Mountain Torrent

Fleet management

Power distribution network supervision

Central heating system supervision

Weather station data transmission

Hydrologic data acquisition

Vending machine

Telemetry, SCADA

Vehicle logistics and diagnostics controlling

Parking meter and Taxi Monitor

Telecom equipment supervision (Mobile base station, microwave or optical relay station)

4. M300 Series Wireless Broadband Modem Spec

Mobile Networks:
GSM EDGE/GPRS;

CDMA1x;

3G UMTS WCDMA (HSDPA/HSUPA/HSPA/HSPA+);

3G TD-SCDMA

3G CDMA EVDO Rev 0 and Rev A;

4G LTE;

Wireless Radio Band:

3G UMTS/HSPA/HSUPA/HSPA/HSPA+ (WCDMA/FDD) 2100Mhz or 850/1900/2100MHz or 850/900/1900/2100Mhz;

2G GSM 900/1800Mhz dual band or 850/900/1800/1900Mhz quad-band;

CDMA1x/EVDO: 800/1900Mhz or 450Mhz option;

3G TD-SCDMA 2010~2025MHz/1880~1920MHz;

4G FDD LTE:

Band 17--700(B17)/AWS

Band 13--700(B13)MHz

Band 20--DD800Mhz

Band 8--900Mhz

Band 12—700Mhz

Band 3--1800Mhz

Band 1--2100Mhz

Band 7--2600MHz

4G TDD LTE:

Band 40 -- 2300Mhz

Band 39 -- 1900Mhz

Band 38 --2600Mhz

Wireless Radio Bandwidth:

HSPA+: Downlink 21/42Mbps, Uplink 5.76Mbps;

HSPA: Downlink 14.4Mbps, Uplink 5.76Mbps;

HSUPA: Downlink 7.2Mbps, Uplink 5.76Mbps;

HSDPA: Downlink 7.2 Mbps, Uplink 384k bps;

WCDMA/UMTS: Downlink/Uplink 384 kbps;

EDGE: Downlink 236,8 kbps, Uplink 118 kbps;

GPRS: Downlink 85.6 kbps, Uplink 42.8 kbps;

CDMA1x: Downlink/Uplink 153.6kbps;

CDMA EVDO:
Rev B: 14.7Mbps downlink, 5.4Mbps uplink
Rev A: 3.1Mbps downlink, 2.4Mbps uplink

Rev O: 2.4Mbps downlink, 153.6kbps uplink

4G LTE: Max. 100Mbps downlink, 50Mbps uplink

3G TD-SCDMA: 2.8Mbps

Antenna

50Ω SMA female interface *3, external detachable;

Antenna for Main Cell, MIMO Cell, GPS

Led

System LED*1

Data LED*1

UIM/SIM Card Slot
Support 1.8V/3V UIM/SIM

USB Port: Mini USB2.0

At Command

Support at command. Packed with GUI software

Power supply:

DC5V-40V , option is DC5V-50V, typical DC9V1A or 12V1A or 12V2A

Power consumption

Peak: 700mA@+9VDC

Average: 85mA@+9VDC

Idle: 30mA@+9VDC

OS

Windows 8, 7, Vista, XP, 2000

Mac OS

Linux

Other OS support internet browser

Physical

Operating Temperature:

Work temperature: -30°C to 70°C option for -30°C to 80°C

Storage temperature: -40°C to 85°C

Humidity: 95% Maximum (Non-condensing)

Dimensions:

Item (L x B x H): 87mm*50mm*23mm

Packaging (L x B x H): 102*70*23mm

PCBA: 84mm*48mm*20mm

Weight: 150g (not including accessories and package)
